Features
♦ 2 Megapixel, 1080P HD camera
♦ Auto iris and auto IR-cut technology
♦ Ambarella DSP 1/2, 7" CMOS image sensor
♦ 2 Megapixel video
♦ High resolution 1920 x 1080
♦ Full-HD SDI output
♦ English-Chinese OSD menu
♦ Built-in IR-CUT optical filter, color rendition in day,
improve the image effect in the night.
♦ DC 12V Power input
Specifications
|
Model |
CVI-W8300-I20 |
|
Image sensor |
1/2.7” CMOS image sensor |
|
System |
PAL |
|
Scanning |
Progressive scanning |
|
Effective resolution |
2 mega |
|
Horizontal resolution |
1920 x 1080 |
|
S/N ratio |
≥50dB |
|
Video output |
1080P |
|
DNR |
Latest 2D/3D DNR, support x2~x256 high lines and low illumination function. |
|
AGC |
Low/middle/high adjusted |
|
White balance |
Auto/manual/preset/indoor/outdoor |
|
Sharpness |
0 ~ 10 steps |
|
Mirror image |
ON/ OFF |
|
Image output |
720P/1080P |
|
Gamma |
0.45 |
|
BLC |
BLC/HSBLC |
|
BLC pattern |
Auto |
|
Electric shutter |
(NTSC:1/30s~50,000s) (PAL:1/25s~1/50,000s) |
|
Exposure |
Electronic exposure |
|
Communication |
RS-485 baud rate: 2400 |
|
Sync system |
Inter-sync |
|
Lens |
4mm,6mm,8mm,12mm,16mm (optional) |
|
IR distance |
50M |
|
Water proof |
IP 66 |
|
Storage temperature |
-20ºC~60ºC |
|
Working voltage |
DC12V±10% |
|
Working temperature |
-20ºC~55ºC |
|
Dimensions |
88mm*95mm*200mm |
|
Weight |
0.85kg |  |
